■ 规格 Specification
|
|
|
系统 System
|
|
处理器 Processor
|
Intel® Wiskey Lake-U i3-8145UE Processor(2.2 GHz,up to 3.9GHz)
Intel® Wiskey Lake-U i5-8365UE Processor(4Cores,1.6 GHz,up to 4.1GHz)
Intel® Wiskey Lake-U i7-8665UE Processor (4Cores,1.7 GHz,up to 4.4GHz)
Intel® Wiskey Lake-U Celeron 4305UE Processor ( 2.0Hz )
|
|
内存 Memory
|
1 x DDR4 2133/2400MHz, up to 32GB(Celeron 4305UE support 2133MHz only)
|
|
存储 Storage
|
1 x SATA 3.0 HDD/SSD bracket
1 x M.2 2242 (SATA3.0/PCIe Gen3 x 4 supported)
1 x mSATA slot
|
|
图形 Graphics
|
Intel® UHD Graphics 620 /Intel® UHD Graphics 610 (Celeron)
|
|
操作系统 OS
|
Windows 10, Linux
|
|
看门狗定时器 Watchdog Timer
|
Programmable 255 levels timer interval, from 1~255 sec/min
|
|
显示屏 Display
|
|
尺寸 Size
|
18.5 inches
|
|
分辨率 Resolution
|
1366(H) × 768(V)
|
|
屏幕宽高比 Ratio
|
16:9
|
|
亮度 Brightness
|
500 nits
|
|
可视角 Viewing Angle
|
89/89/89/89 (Typ.)(CR ≥ 10)
|
|
对比度 度 Contrast Ratio
|
1000
|
|
背光 Backlight
|
LED Backlight
|
|
背光寿命 Backlight Lifetime
|
50000Hrs
|
|
触摸屏 Touch Screen
|
|
触摸屏 Touch Type
|
10 点投射式电容屏 P-cap Multi-Touch
|
|
触击 Touch
|
35,000,000 times
|
|
外部接口 External I/O
|
|
串口 COM
|
2 x RS232/RS422/RS485(COM1~2)
2 x RS232(COM3 & COM4)
|
|
USB
|
4 x USB 3.1Gen2 (USB SR Pro supported) 1x USB 2.0 on the front panel
|
|
网口 Ethernet
|
1 x RJ45 Intel® I219-LM GbE (10/100/1000 Mbps)
2 x RJ45 Intel® I210AT (10/100/1000 Mbps)
|
|
显示 Video
|
1 x HDMI (up to 4096 x 2160@24Hz)
|
|
音频 Audio
|
1 x Audio(Line-out&Mic-in 2 in 1), Realtek® ALC888S HD Audio codec
|
|
扬声器 Speaker
|
2 x Speaker Out (3W/4ohm)
|
|
远程开关 Remote ON-OFF
|
1 x Remote ON-OFF
|
|
电源输入 Power Input
|
1 x Power Connector (2P Phoenix)
|
|
内部接口 Internal I/O
|
|
扩展接口 Expansion
|
1 x Mini-PCIe (WiFi/3G/4G/mSATA supported)
1 x M.2 2230 (WiFi/PCIe/USB2.0 signal supported)
1 x M.2 2242 (SATA/PCIe X4 NVME SSD supported)
1 x SIM socket
|
|
环境 Environmental
|
|
操作温度 Operating Temp.
|
-10℃ ~ 50℃ (SSD), 0℃ ~ 40℃ (HDD)
|
|
存储温度 Storage Temp.
|
-40℃ ~ 70℃
|
|
湿度 Relative Humidity
|
5% ~ 95%, 非凝结状态 Non-condensing
|
|
随机振动 Random Vibration
|
5~500Hz, 1Grms (HDD)operation, 5~500Hz, 2Grms (SSD)operation
|
|
正弦振动 Sine Vibration
|
5~500Hz, 2G Non-operation
|
|
机械冲击 Shock
|
10g 11ms operation, 30g 11ms Non-operation
|
|
前面板防护 Ingress Protection
|
Front panel IP66
|
|
机构 Mechanical
|
|
前框 Front Panel
|
铝 Aluminum
|
|
铝挤 Heat-Sink
|
铝 Aluminum
|
|
底板 Rear Cover
|
铁 SECC
|
|
安装方式 Mounting
|
Panel Mount, Wall and VESA-mount (75x 75mm)
|
|
尺寸 Dimension
|
483(W) x 337(H) x73(D)mm
|
|
建议开孔尺寸 Cut Out
|
463.9 x 317.9mm
|
|
重量 Weight
|
7.2Kg
|
|
电源 Power
|
|
电源输入 Power Input
|
12V-7.5A DC-IN
|
|
认证 Certification
|
|
安规认证 Safety Certification
|
CCC/FCC/CE
|
|
■ 配置 Configuration
|
|
型号 Model
|
处理器CPU
|
|
CEP-18PW-814J
|
Intel® Wiskey Lake-U i3-8145UE Processor(2.2 GHz, up to 3.9GHz）
|
|
CEP-18PW-836J
|
Intel® Wiskey Lake-U i5-8365UE Processor( 1.6 GHz, up to 4.1GHz）
|
|
CEP-18PW-866J
|
Intel® Wiskey Lake-U i7-8665UE Processor (1.7 GHz, up to 4.4GHz)
|
|
CEP-18PW-430J
|
Intel® Wiskey Lake-U Celeron 4305UE (2.0GHz)
|
|
■ 订购清单 Order List
|
|
标配
Standard
|
型号
|
配置信息
|
|
34046QH00-GLA-G
|
1x2P DC in Phoenix conn(5.00), female
|
|
34046QJ00-600-G
|
Conn,3.5mm,PA,DIP-2,FIT,TEPE123-11G00-DF
|
|
1A03DV400-88A-G
|
panel hook (4pcs in 1 package)
|
|
选配
Optional
|
型号
|
配置信息
|
|
350744V00-704-G
|
150cm AC power cord
|
|
870111B00-289-G
|
Adapter,input 100V~240V,output 12V,90W
|
